Rosemount 2090P Pulp and Paper Pressure Transmitter
A flush-mount pressure transmitter engineered for pulp and paper stock, with an isolation diaphragm positioned flush to the vessel or pipe wall to resist clogging, supplied to Canadian industry with duty-paid delivery.
Instrubiz sources genuine Rosemount 2090P transmitters for pulp and paper manufacturing facilities across Ontario, and process operations across Alberta.
Competitive Pricing
Genuine components, fair market rates
Efficient Lead Times
Clear stock & delivery communication
Duty-Paid Delivery
Door-to-door across Canada, no surprises
Rosemount 2090P Pulp and Paper Pressure Transmitter Overview
Flush-Mount Pressure Measurement for Pulp and Paper Stock
The Rosemount 2090P Pulp and Paper Pressure Transmitter measures absolute or gauge pressure up to 300 psi through a process connection designed specifically for viscous, fibrous pulp and paper stock. Its isolation diaphragm sits flush with the vessel or pipe wall, eliminating the clogging problems a recessed diaphragm would face in stock prone to fiber buildup, crystallization, or polymerization.
It is available in a 1 inch flush-mount connection compatible with the PMC process connection, or a 1.5 inch threaded mounting connection, calibrated across spans from 0 to 1.5 psi up to 0 to 300 psi with 20:1 rangedown. A single-filled sensor system delivers accuracy of plus or minus 0.20 percent of span standard, with an optional plus or minus 0.10 percent high-accuracy version.
Output is 4-20 mA with selectable HART protocol. This is a specialized, lower-volume product built around the flush-mount connection rather than the accuracy or rangedown Rosemount’s general process platforms compete on.
It is available in a 1 inch flush-mount connection compatible with the PMC process connection, or a 1.5 inch threaded mounting connection, calibrated across spans from 0 to 1.5 psi up to 0 to 300 psi with 20:1 rangedown. A single-filled sensor system delivers accuracy of plus or minus 0.20 percent of span standard, with an optional plus or minus 0.10 percent high-accuracy version.
Output is 4-20 mA with selectable HART protocol. This is a specialized, lower-volume product built around the flush-mount connection rather than the accuracy or rangedown Rosemount’s general process platforms compete on.
Sensing Principle
Single-Filled Flush-Mount Sensor
Measures
Absolute / Gauge Pressure
Process Connection
1″ Flush-Mount (PMC) or 1.5″ Threaded
Accuracy
±0.20% standard, ±0.10% high-accuracy option
Need pricing for the Rosemount 2090P Pulp and Paper Pressure Transmitter?
Rosemount 2090P Product Detail
The Rosemount 2090P Pulp and Paper Pressure Transmitter
2090P
Rosemount 2090P Pulp and Paper Pressure Transmitter
Measures absolute or gauge pressure through a flush-mount isolation diaphragm designed to resist clogging in viscous pulp and paper stock, up to 300 psi.
Rosemount 2090P Pulp and Paper Pressure Transmitter Base Model Numbers
Rosemount 2090P Pulp and Paper Pressure Transmitter, base model numbers
Base model codes confirmed from Rosemount’s published ordering documentation.
| Model | Type | Status |
|---|---|---|
| Rosemount 2090P | Flush-Mount Absolute / Gauge Pressure | Available to Order |
Applications
Rosemount 2090P Pulp and Paper Pressure Transmitter applications
Pulp & Paper Stock Consistency
Pressure measurement on fibrous stock lines where a recessed diaphragm would clog.
Chemical Processing
Viscous or crystallizing media where a flush-mount connection prevents buildup on the sensing diaphragm.
Digester & Bleaching Process Monitoring
Vessel pressure on pulp processing equipment.
Preventative Maintenance
A modest investment in reliable pressure measurement directly protects facility and equipment investments from unplanned breakdowns.
Regions We Serve
Where Instrubiz Supports the 2090P in Canada
Alberta
Alberta’s process facilities specify the 2090P wherever viscous or fiber-laden media would clog a standard recessed diaphragm. Instrubiz supplies genuine 2090P transmitters for both new installations and replacements.
Ontario
Ontario’s pulp and paper manufacturing facilities are the primary market for the 2090P in Canada. Instrubiz supplies genuine 2090P transmitters with the technical background to help confirm the right process connection for the application.
